ULTEM 9085 Description

ULTEM™ 9085 resin is a high-performance FDM 3D printing thermoplastic known for its exceptional strength-to-weight ratio, high thermal and chemical resistance, and flame-retardant properties. ULTEM™ 9085’s compliance with aerospace industry standards for flame, smoke, and toxicity (FST) makes it an ideal choice for applications requiring robust performance under demanding conditions. ULTEM™ 9085 is suitable for producing functional prototypes, end-use parts, and durable tooling. Its versatility and reliability have made it a preferred material for manufacturers aiming to achieve lightweight yet strong components.

Available Colors

Tan    Black

ITAR Registered

Endeavor 3D is ITAR registered, enabling us to work on projects involving defense-related articles and services.

Collaborating with Industry Leaders

Key Attributes

ULTEM 9085 Benefits

  • Flame, smoke, and toxicity (FST) rated
  • Aerospace grade availability
  • High heat resistance
  • Durable and lightweight

ULTEM 9085 Properties

  • Tensile strength: XZ (69.2 MPa), ZX (39.4 MPa)
  • Tensile Elongation @ break: XZ (5.4%), ZX (1.9%)
  • Flexural Strength: XY (104 MPa), ZX (73.1 MPa)
  • IZOD Impact Notched: XY (88.5 J/m), ZX (39.2 J/m)
  • Heat Deflection Temperature @ 264 psi: 343°F (172.9°C)

ULTEM 9085 Applications

  • Commercial transportation applications
  • Durable tooling and fixtures
  • Aerospace components
  • Functional prototypes

Industries

Automotive

Aerospace

Industrial

Medical

Print high-quality parts with Endeavor 3D using ULTEM 9085 material and FDM 3D printing technology.

Print High-Quality ULTEM 9085 Parts
