PA 12 White Description

PA 12 W (White) is a versatile material that retains the excellent mechanical properties of Nylon PA 12 W and can absorb dyes with vibrant pigments. This nylon-based material is perfect for producing functional prototypes, complex geometries, and customizable end-use parts. The natural white coloration of PA 12 W produced by the printer enhances the aesthetic appeal of the final product. Its biocompatibility and low moisture absorption make it ideal for consumer goods, medical, and automotive applications.

Deprecated: Your theme "Porto Child" template override for WPBakery template "vc_btn.php" is outdated (version not set) compared to the default (version 9.0). Contact theme author update it to avoid compatibility issues. in /home/u928133122/domains/endeavor3d.com/public_html/wp-includes/functions.php on line 6260
Request a Quote

Collaborating with Industry Leaders

PA 12 W Benefits

  • Ease of dyeing
  • High mechanical strength
  • Low moisture absorption
  • Biocompatible
  • Chemical resistance
  • Aesthetic appeal

PA 12 W Properties

  • Tensile strength (MPa): 48
  • Density ( g/cm³): 1.01
  • Elongation at break (%): 17 (XY) 9 (Z)
  • Impact Strength (kJ/m²): 4.8 (XY), 4.1 (Y)
  • Heat Deflection Temperature @ 0.46 MPa: 350°F
  • Powder Melting Point: 369°F
  • Biocompatibility: Meets USP Class I-VI and US FDA guidance for Intact Skin Surface Devices

PA 12 W Applications

  • Prosthetics
  • Orthotics
  • Household appliances
  • Biocompatible parts
  • Housing and enclosures
  • Prototypes
  • Consumer products

Powered by Multi Jet Fusion

Nylon PA 12 W leverages the advanced capabilities of Multi Jet Fusion (MJF) 3D printing technology. MJF 3D printing offers unparalleled benefits for PA 12 W 3D printing including:

High Precision and Detail: MJF ensures excellent surface quality and intricate detailing, achieving layer thicknesses as fine as 80 microns and dimensional tolerances within ±0.012 in., ensuring high accuracy.

Fast Production Speed: MJF 3D printing can produce parts up to 10 x faster than SLS 3D printing, making it ideal for rapid manufacturing and serial production.

Consistent Quality: MJF provides consistent mechanical properties across builds with a repeatability of ±0.3%, ensuring reliable and repeatable results.

Efficient Material Usage: MJF 3D printing with PA 12 W material utilizes up to 80% of the material, significantly reducing waste and making it a cost-effective solution.


Deprecated: Your theme "Porto Child" template override for WPBakery template "vc_btn.php" is outdated (version not set) compared to the default (version 9.0). Contact theme author update it to avoid compatibility issues. in /home/u928133122/domains/endeavor3d.com/public_html/wp-includes/functions.php on line 6260
Learn more

Warning: Undefined variable $img_link_target in /home/u928133122/domains/endeavor3d.com/public_html/wp-content/themes/porto/vc_templates/vc_single_image.php on line 304

Print high-quality parts with Endeavor 3D using Nylon PA 12 W material and MJF 3D printing technology


Deprecated: Your theme "Porto Child" template override for WPBakery template "vc_btn.php" is outdated (version not set) compared to the default (version 9.0). Contact theme author update it to avoid compatibility issues. in /home/u928133122/domains/endeavor3d.com/public_html/wp-includes/functions.php on line 6260
Request a Sample
